Coarse Thread |
|||
|---|---|---|---|
d |
s |
e |
m |
| M3 | - | - | - |
| M4 | - | - | - |
| M5 | - | - | - |
| M6 | - | - | - |
| M8 | 13 | 14.38 | 5 |
| M10 | 17 | 18.90 | 6 |
| M12 | 19 | 21.10 | 7 |
| M14 | 22 | 24.49 | 8 |
| M16 | 24 | 26.75 | 8 |
| M18 | 27 | 29.56 | 9 |
| M20 | 30 | 32.95 | 9 |
| M22 | 32 | 35.03 | 10 |
| M24 | 36 | 39.55 | 10 |
| M27 | 41 | 45.20 | 12 |
| M30 | 46 | 50.85 | 12 |
| M36 | 55 | 60.79 | 14 |
| M42 | 65 | 71.3 | 16 |
